DorfitConcealed Hinges
| Item Code | DTCH |
| Material | Zinc Alloy Body with Stainless Steel Connecting Strips |
| Finish | Satin Nickel |
| Maximum Opening Angle | 180° |
| Accessories included | Screws |
- Concealed Installation
- Hinge Completely Invisible When Door Is Closed
- Applicable For Wooden And Metal Doors
| Item Code | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | H (CTC) |
| DTCH003 | 13 | 45 | 9 | 19 | 0.8 | 18 | 5 | 30.5 |
| DTCH004 | 13 | 60 | 9 | 30.5 | 0.8 | 18 | 6 | 47 |
| DTCH005 | 16 | 70 | 11 | 34 | 0.8 | 22.5 | 7 | 51 |
| DTCH006 | 19 | 95 | 13 | 51.2 | 1.2 | 27 | 9 | 73 |
| DTCH008 | 28 | 118 | 22 | 61.5 | 1.4 | 41 | 9.5 | 93 |
| DTCH009 | 34 | 140 | 27.5 | 74.5 | 1.6 | 51 | 11.5 | 113.5 |
| Item Code | Door Thickness (mm) | Load Capacity (KG) |
| DTCH003 | 20 | 5 |
| DTCH004 | 20 | 10 |
| DTCH005 | 25 | 15 |
| DTCH006 | 30 | 25 |
| DTCH008 | 40 | 40 |
| DTCH009 | 50 | 50 |
